AUTOMATIC BGA REWORK STATION

Description

VD-6200 – Automatic BGA Rework Station

The VD-6200 BGA Rework Station is a high-performance, precision tool designed for complex BGA, CSP, and SMD rework processes. This station is equipped with advanced features, including an optical camera module for precise alignment during the soldering process, making it an ideal solution for technicians and manufacturers working with sensitive PCB assemblies.

The built-in camera module ensures accurate chip alignment by focusing on both the IC ball and the PCB track, significantly improving soldering precision. The VD-6200 offers a user-friendly touch-screen interface controlled by a Mitsubishi PLC, allowing operators to manage temperature profiles, control the heating zones, and monitor the alignment process in real-time.

The machine is equipped with a sophisticated temperature control system that includes three independent heating zones: top hot air, bottom hot air, and bottom IR heating, ensuring even heat distribution and minimizing the risk of PCB deformation. The high-precision V-groove positioning system, adjustable X, Y, and Z axes, and powerful cooling fan further ensure a successful rework process.

Key Features:

• Optical Camera for Alignment: Allows for precise chip and solder ball alignment, ensuring high-quality solder joints.
• Advanced Temperature Control: Three independent heating zones (top and bottom hot air, bottom IR) with real-time temperature control, providing exceptional accuracy.
• Mitsubishi PLC Control: Offers a reliable and user-friendly interface with touchscreen control for temperature and operation monitoring.
• High Precision Positioning: Equipped with an adjustable V-groove PCB holder and micro-adjustable X, Y, Z axes for accurate placement.
• Powerful Cooling System: Cross-flow fan for rapid PCB cooling, preventing deformation and ensuring optimal soldering results.

Specifications:

The VD-6200 BGA Rework Station combines precision, efficiency, and advanced features, making it an indispensable tool for electronics manufacturing and repair. Its camera alignment system, combined with robust temperature control, ensures consistent, high-quality rework results, even on the most complex PCB assemblies.
